C6

6,5″/1.75″ coaxial installation loudspeaker

Specifications
Specifications
Description

The Quint Audio C6 is a compact yet powerful 6.5″/1.75″ coaxial installation loudspeaker designed for high quality audio reproduction mechanical and live music especcially and in electro-acoustical situations where controlled dispersion is of the essence.

The system is based on a specially shaped coaxial woofer/horn/driver combination that guarantees an extraordinary constant directivity of 80 degrees conical over the entire mid and high frequency spectrum.

With its unique internal rigging system C6 is very easy to install. It can be flush mounted on walls and in (and on) corners and it can be coupled with other cabinets with ease.


Application area

near field loudspeaker

speech
live music
mechanical music


Specifications
C6
6,5"/1.75" coaxial
passive 1ch DSP control
200W
400W
16 Ohms
95dBWm
118dB 1m
126dB 1m
60Hz-20kHz
80° conical
6 kg / 13 lb
236 x 270 x 198 mm / 9.3 x 10.6 x 7.8 in

Advised electronics

P4 processor
A1 amplifier
A23 amplifier
A41 amplifier
A42 amplifier


Downloads

Rigging
