C30

2×15″/2×15″ANC/1×4”-2.5” coaxial Active Noise Cancelling full range loudspeaker

Specifications
Specifications
Description

The Quint Audio C30-ANC is a high performance full range Active Noise Cancelling (ANC) loudspeaker designed for near- and mid-field PA applications in clubs and halls.

The Active Noise Cancelling C30-ANC can be used with standard settings or can be tuned in to a specific room with specific distances to the walls for maximum noise cancelling efficiency.

For even higher output levels, the C30-ANC can of course be combined with any of our available ANC subwoofers.


Application area

active noise cancelling club loudspeaker

live music
mechanical music


Specifications
C30
2x15"/2x15"ANC/1x4”-2.5” coaxial
3-channel DSP control (optional 4-channel DSP control)
Front 2400W / ANC 2400W / 110W MF-HF
Front 4800W / ANC 4800W / 220W MF-HF
LF & ANC 4Ohms / MF & HF 8Ohms
Front & ANC 100dBWm / MF-HF 109dBWm
Front 134dB & ANC 134dB / MF-HF 130dB 1m
Front 140dB & ANC 140dB / MF-HF 136dB 1m
40Hz-19kHz
70°H x 40°V
85 kg / 187 lb
900 x 490 x 830 mm / 35.4 x 19.3 x 32.7 inch

Advised electronics

P4 processor
A1 amplifier
A23 amplifier
A41 amplifier
A42 amplifier
