C4

4″/1″ coaxial installation loudspeaker

Specifications
Specifications
Description

The Quint Audio C4 is an ultra compact loudspeaker with high audio specifications.

It is designed as fill on stage lips, under balcony, monitoring in live and broadcast environments, but also use as a compact AV loudspeaker, background music loudspeaker and micro theater fill-in.

The tiny C4 can be even suitable as a small permanently installed PA top with a subwoofer for a clear speech and a music .




Application area

near field applications

speech
mechanical music


Specifications
C4
4"/1"coaxial
1ch DSP control
100W
200W
8 Ohms
91dBWm
114dB 1m
120dB 1m
100Hz-18kHz
100° conical
2,5 kgs / 5 lb
124 x 124 x 124 mm / 4.9 x 4.9 x 4.9 inch

Advised electronics

P4 processor
A1 amplifier
A23 amplifier
A41 amplifier
A42 amplifier
