D-series · Control panel
D5
Quint console control panel — 5" touchscreen
01 / 01
5 Ohm
Touchscreen
4× RJ45
Network
1.6 kg
Weight
0.5×2 U
Size
Touchscreen interface for P-series.
Connector panel for easy access. Fits perfectly with D4, D8 or D0. Integrated switch and 5 Ohm touchscreen.
Overpowering security with PowerCon True out.
Specifications
Specifications.
Measurements conform to AES75, carried out with P9 processor and A42 amplifier. Values are scaled to 1 m free field.
Overview
| Type | Accessory |
| Power / IO | — |
| Application | Touring & Installation |
| Series | D-series |
Connectivity
| Network | 4x RJ45 |
| Output | True PowerCon, with overvoltage protection |
| Mains connector | True PowerCon |
| Mains | 100-240 V |
| AC mains frequency range | 50/60 Hz |
| Weight | 1.6 kg |
| Dimensions (wxh) | 0.5x2 U (HE) |
Advised electronics
Works with.
Rigging & manuals
Mounting.
D0
D0
Plate
D-mount
D-mount
Mounting brackets
