S218

The Quint Audio S218 is a dual 18″ ND subwoofer with a linear bass reflex tuning to be used as (sub)bass extension of Quint Audio loudspeakers

Specifications
Specifications
Description

On request of many users, the Quint Audio S218 was built as a dual version of the S18 subwoofer. It has the same output power and the same sound character as two perfectly coupled single S18 subwoofers, though for many users it provides easier handling.

Like the whole S-series subs, the S18 is associated with a deep and powerful bass foundation and high linearity that is well appreciated by both on- and off-stage people.

The versatile 2×18″ sub is virtually deployable in all thinkable PA-applications.


Application area

Concert Sub
PA Sub
Cardioid Setup
EndFire Setup

Live Music
Mechanical Music


Specifications
S218
2x18" bassreflex sub
none
3200W
6400W
4 Ohms
100 dB 1W/1m
138 dB 1m
144dB 1m
37 - 400Hz
omni
84 kg
1160 x 580 x 680 mm

Advised electronics

P4 processor
A23 amplifier
A41 amplifier
A42 amplifier


Downloads

Rigging
